What Is an NC Roller Feeder?
An NC roller feeder uses servo-driven rollers to feed coil strip into a press with numeric precision. A closed-loop feedback system tracks the feed for accuracy.
The NCF Series adds pneumatic electronic release, synced with press cam signals for fast release-angle setup.
التطبيقات
- Progressive die stamping
- Automotive structural parts
- Appliance panel stamping
- ختم العُدد الدقيق
- Appliance metal stamping of housings and panels — اعرف المزيد
الطرازات والأحجام
| الطراز | العرض (مم) | طول التغذية (مم) | Servo Motor |
|---|---|---|---|
| NCF-100 | 100 | 9999.99 | AC0.8 |
| NCF-300 | 300 | 9999.99 | AC1.5 |
| NCF-500 | 500 | 9999.99 | AC2 |
| NCF-800 | 800 | 9999.99 | AC2.6 |
| NCF-1300 | 1300 | 9999.99 | AC3 |
المواصفات الفنية
| Material width | 100–1300 mm |
| سمك المادة | Std. 0–3.2 mm / A 0–4.5 mm |
| Feeding length | Max 9999.99 mm |
| دقة التغذية | ±0.03 mm |
| Voltage | 220V/1ph (≤300) · 380V/415V 3ph (≥400) |
المزايا الرئيسية
High-Precision Feeding
Computer closed-loop feedback holds accuracy within ±0.03 mm.
Programmable Multi-Stage Feeding
Store up to 20 feed-length groups for multi-variety production.
Pneumatic Electronic Release
Quick release-angle setup syncs with press cam signals.
تكامل الخط
Feed coil stock with a آلة فكّ اللفة و آلة تسوية before this NC roller feeder. Explore the full servo NC feeder range, then add a روبوت مناولة for the press.
الأسئلة الشائعة
What accuracy does the NC roller feeder achieve?
Feeding accuracy is within ±0.03 mm.
Can it run multiple feed lengths?
Yes, up to 20 preset length groups are supported.
What thickness does it handle?
Standard 0–3.2 mm, with the A version up to 4.5 mm.
اطلب عرض سعر
اتصل بنا for a quote on the NCF Series NC roller feeder.
